Click here for mag well install.
Step 1 - Cleaning: Before wrapping your Mag, it is vital to thoroughly inspect, prep, and clean the surface. Make sure your mag is empty before beginning the application process. Oil and grease will be present and must be completely removed. If not, the material will not properly stick to the surface. We recommend using a degreaser formulated for guns to remove any oil or grease from your gun's surface.
Isopropyl alcohol should be used to remove any residue left behind. Wrapping your mag with your bare hands may add natural oil or grease to your mag, so we recommend washing your hands with dish soap after cleaning your mag prior to installation.
Step 2: Draw a line all around the mag following the rim of the gun with a pencil. See below
Remove the mag
Use the green cut tape to create a trim line. Apply the tape so that the bottom of the tape meets the top of the line drawn with pencil. See below
Align the mag wrap to the center of the front of mag using the v cuts as a guide. See below
Wrap one side first (some heat and slight bending will be required to follow the shape of the mag). There are relief cuts to assist with the shaping process. Wrap the other side after trimming the first side. Shown below
Step 3 - Detail trim: Now you can cut along the bottom of the green tape. Remove the excess wrap and the green tape. See below
Heat the mag and apply firm pressure to make sure you have a good bond.
Enjoy your MagWrap
Step 1 - Cleaning: Before wrapping your Magwell, it is vital to thoroughly inspect, prep, and clean the surface. Make sure your gun is empty before beginning the application process. Oil and grease will be present and must be completely removed. If not, the material will not properly stick to the surface. We recommend using a degreaser formulated for guns to remove any oil or grease from your gun's surface.
Isopropyl alcohol should be used to remove any residue left behind. Wrapping your mag with your bare hands may add natural oil or grease to your mag, so we recommend washing your hands with dish soap after cleaning your mag prior to installation.
Step 2: Apply all pieces as shown below. Our kits are universal and may require additional trimming for a custom fit. Line the pieces up and apply firm pressure using your fingers or glove.
Step 3: Heat the magwell area and apply firm pressure to make sure you have a good bond.
Enjoy your new personalized magwell
AK-47 Mag Install
Step 1 - Cleaning: Before wrapping your Mag, it is vital to thoroughly inspect, prep, and clean the surface. Make sure your mag is empty before beginning the application process. Oil and grease will be present and must be completely removed. If not, the material will not properly stick to the surface. We recommend using a degreaser formulated for guns to remove any oil or grease from your gun's surface.
Isopropyl alcohol should be used to remove any residue left behind. Wrapping your mag with your bare hands may add natural oil or grease to your mag, so we recommend washing your hands with dish soap after cleaning your mag prior to installation.
Step 2: Align the mag wrap to the center of the front of mag using the v cuts as a guide. See below
Wrap one side (some heat and slight bending will be required to follow the shape of the mag). There are relief cuts to assist with the shaping process. Wrap the other side after trimming the first side. See below
Pistol Mag Install
Step 1: Before wrapping your Mag, it is vital to thoroughly inspect, prep, and clean the surface of your gun. Make sure your gun is empty before beginning the application process. Oil and grease will be present and must be completely removed. If not, the material will not properly stick to the surface. We recommend using a degreaser formulated for guns to remove any oil or grease from your gun's surface.
Isopropyl alcohol should be used to remove any residue left behind. It is helpful to use a small soft brush to scrub into the crevices of your Mag to ensure that your gun is clean. Wrapping your Mag with your bare hands may add natural oil or grease to your gun, so we recommend washing your hands with dish soap after cleaning your gun prior to installation.
Center the wrap to the bottom of the mag and apply firm pressure to make sure you have a good bond. Trim excess and enjoy your new mag wrap accent.
